Weight：Model:1000W
Output waveform:Pure sine wave
Rated Power :1000W
Surge power :2000W
Rated Input volt :DC12V
Input voltage range:10V-DC15.5V / 20-30DC
Frequency:50HZ / 60HZ +/-3HZ
Output volt:100VAC or 110VAC or 120VAC ±5% (220VAC or 230VAC or 240VAC ±5%)
Frequency:50 / 60Hz
Efficiency：>90%
Cooling Way：Fans
No load current draw：<0.5A
AC Regulation：<5%
Battery chip cord length：70cm(optional)
Distortion Rated：<5%
Size：320*150*90mm
Net Weight / Gross Weight：2.51/3.17kg
Protection Specialty
Input Low Voltage Protection：DC10.5V+/-0.3V，DC21+-0.3V
Input High Voltage Protection：>DC15.5V / DC30V
Over Thermal：Shut Off Output Automatically
Low Input Voltage Alarm：<DC10V / DC20V
Output Overload >2300W Protect Time：30 seconds
Output Short-circuit Protection time：2～3 seconds
Input Anti-access Protection：automatic recovery
Temperature Protection：>65℃
Start：Soft Start
Operating temperature：‘-20 oC~ + 50oC
Storage temperature：’-30 oC~ + 80oC
Output overload（>2500W）Protection time：2～3 seconds
